S19 Data Cable Reset Switch

This clever device allows you to get around the S19 testing firmware's requirement to unplug the cable after every test! With a simple press of a button, it signals the tester that the board has been unplugged, allowing you to extend the life of your cables by not having to plug them in multiple times for voltage checks.

The PCB this circuit is crafted on is made out of aluminum allowing the highest possible current draws on the data cable without failure, and with the super wide copper tracks, signal integrity is crystal clear, its as if it isn't there when plugged in and running.

Disclaimer - Product shown has black solder mask, the final product that you will receive is white
